Description
Excavator Grapple - GRX Series from Intermercato for Mini Excavators
The GRX Series Grapples are suited for excavators up to 13 tons. With many configurations for different applications such as stone, logs and demolition. The Intermercato grapple is the original mini excavator grapple engineered and manufactured in Sweden.
The GRX Series have a universal hole pattern that can be built with a rotator or a fixed mount to suit the application or excavator capabilities.
Manufactured with a combination of Hardox and Strenx steel mean that the grapple is light but strong, to allow for a maximum lift capacity.
GRX Log Grapple
GRX 15 Excavators from 3-6 tons!
- Weight: 200lbs
- Capacity: 5 cubic feet
- Clamping Force: 1,620lbf
GRX 20 Excavators from 5-9 tons!
- Weight: 365lbs
- Capacity: 7 cubic feet
- Clamping Force: 2,540lbf
GRX 25 Excavators from 8-13 tons!
- Weight: 523lbs
- Capacity: 8.8 cubic feet
- Clamping Force: 3,350lbf
GRX 5 Finger Grapple
GRX 15-5 Excavators from 3-6 tons!
- Weight: 200lbs
- Capacity: 5 cubic feet
- Clamping Force: 1,620lbf
GRX 20-5 Excavators from 5-9 tons!
- Weight: 375lbs
- Capacity: 7 cubic feet
- Clamping Force: 2,540lbf
GRX 25-5 Excavators from 8-13 tons!
- Weight: 523lbs
- Capacity: 8.8 cubic feet
- Clamping Force: 3,350lbf
GRX EG Demolition/Sorting Grapple
GRX 15 EG Excavators from 3-6 tons!
- Weight: 225lbs
- Capacity: 5 cubic feet
- Clamping Force: 1,620lbf
GRX 20 EG Excavators from 5-9 tons!
- Weight: 396lbs
- Capacity: 7 cubic feet
- Clamping Force: 2,540lbf
GRX 25 EG Excavators from 8-13 tons!
- Weight: 578lbs
- Capacity: 8.8 cubic feet
- Clamping Force: 3,350lbf
Machine Requirements
- For a fixed grapple (without rotation) only 1 auxiliary hydraulic circuit is needed on the excavator
- For a rotating grapple 2 auxiliary hydraulic circuits are needed on the excavator. One circuit to open/close the grapple, and one to run the rotator
- If you have any questions about your machines suitability contact us here or call (941) 212 0037.
Warranty Information
Intermercato manufactures all of their attachments in Sweden to the highest standard and therefore we offer a comprehensive 2 year warranty on all Intermercato grapple attachments. The Attachment Company also carry a comprehensive list of spare parts.
If you have any questions about your machines suitability, the attachment or warranty contact us here or call (941) 212 0037.
