Excavator Rotating Grapple – MB America – Excavators Up To 30 Tons

In Stock

$9,041.00$30,604.00

The MB range of Grapples offer the most versatility, efficiency and best build quality on the market.

Designed to select and handle any type of solid material. Thanks to the interchangeable claws and the 360° rotation.

Available for excavators equipped with 1 or 2 auxiliary hydraulic circuits. Come with hoses and mount to suit your excavator(s).

Description

Excavator Rotating Grapple from MB America!

Rotating Grapples for Excavators from 1.5 to 30 tons!

MB Excavator Rotating Grapple available for all sizes of excavators. MB manufacture attachments for the demolition and concrete industry. Famous for their crusher and screening bucket, they also have a range of other tools for excavators to guarantee the best efficiency available. An excavator grapple gives you maximum flexibility for your machine with endless rotation and a large capacity.

The MB range of Grapples offer the most versatility, efficiency and best build quality on the market. Designed to select and handle any type of solid material. Thanks to the interchangeable claws and the 360° rotation.

You can also visit the MB website here!

Grapple Features

  • Inclined mounting increase’s the attachment reach
  • Equipped with a safety valve that prevent the claws from opening in case of a pressure loss
  • Bolt on replaceable, double sided blades
  • Optional bolt on side plates for handling specific material
  • Optional kit for 2 hose functionality (let’s you rotate and operate the grapple with only 1 hydraulic circuit on the machine)

Grab Models

G350 Grapple

Excavators from 1-5 – 3 tons!

  • Width: 14″
  • Opening Max: 31″
  • Total Height: 20″
  • Height inside jaws when shut: 11″
  • Capacity: 0.04 cubic yards
  • Weight: 187lbs
  • Oil pressure (rotation): 2,175psi
  • Oil flow rate (rotation): 1.3 GPM
  • Oil pressure (opening/closing): 0 – 2,901psi
  • Oil flow rate (opening/closing): 4 GPM

G450 Grapple

Excavators from 3 – 6 tons!

  • Width: 19″
  • Opening Max: 51″
  • Total Height: 30″
  • Height inside jaws when shut: 20″
  • Capacity: 0.13 cubic yards
  • Weight: 635lbs
  • Oil pressure (rotation):  > 2,175psi
  • Oil flow rate (rotation): 2.6 GPM
  • Oil pressure (opening/closing): 0 – 3,626psi
  • Oil flow rate (opening/closing): 11 GPM

G600 Grapple

Excavators from 6 – 12 tons!

  • Width: 26″
  • Opening Max: 73″
  • Total Height: 54″
  • Height inside jaws when shut: 29″
  • Capacity: 0.38 cubic yards
  • Weight: 1,323lbs
  • Oil pressure (rotation):  > 2,321psi
  • Oil flow rate (rotation): 4-8 GPM
  • Oil pressure (opening/closing): 2,901 – 4,351psi
  • Oil flow rate (opening/closing): 7 GPM

G900 Grapple

Excavators from 12 – 18 tons!

  • Width: 36″
  • Opening Max: 73″
  • Total Height: 54″
  • Height inside jaws when shut: 29″
  • Capacity: 0.56 cubic yards
  • Weight: 1,720lbs
  • Oil pressure (rotation):  > 2,321psi
  • Oil flow rate (rotation): 4-8 GPM
  • Oil pressure (opening/closing): 2,901 – 4,351psi
  • Oil flow rate (opening/closing): 8 GPM

G1000 Grapple

Excavators from 14 – 25 tons!

  • Width: 40″
  • Opening Max: 71″
  • Total Height: 59″
  • Height inside jaws when shut: 25″
  • Capacity: 0.58 cubic yards
  • Weight: 3,571lbs
  • Oil pressure (rotation):  > 3,191psi
  • Oil flow rate (rotation): 11-19 GPM
  • Oil pressure (opening/closing): 4351 – 5802psi
  • Oil flow rate (opening/closing): 19 GPM

G1200 Grapple

Excavators from 20 – 30 tons!

  • Width: 49″
  • Opening Max: 83″
  • Total Height: 65″
  • Height inside jaws when shut: 32″
  • Capacity: 0.93 cubic yards
  • Weight: 3,637lbs
  • Oil pressure (rotation):  > 3,191psi
  • Oil flow rate (rotation): 5-9 GPM
  • Oil pressure (opening/closing): 4351 – 5802psi
  • Oil flow rate (opening/closing): 19 GPM

Machine Requirements

  • 2 Auxiliary Hydraulic Circuits – to enable both open/close as well as rotation of the grapple the parent machine must have two auxiliary hydraulic circuits.
  • If your machine only has 1 Auxiliary Hydraulic Circuit – the electrical kit for 2 hose functionality is required. This lets the operator switch for open/close to rotation from a button inside the cab.
  • If you have any questions about your machines suitability contact us here or call (941) 212 0037.

 Warranty Information

MB manufactures all of their attachments in Italy to the highest standard and therefore we offer a comprehensive 2 year warranty on all MB attachments.

If you have any questions about your machines suitability, the attachment or warranty contact us here or call (941) 212 0037.

If you can’t find the answer to your question, contact us below!

Additional information

Model

G350 (1.5 – 3t), G450 (3 – 6t), G600 (6 – 12t), G900 (12 -18t), G1000 (14-25t), G1200 (20 – 30t)
